디젤 엔진 배기 가스 처리 시스템을위한 세 배 특기 해상 나비 밸브 고 성능
| 원래 장소 | 중국 |
|---|---|
| 브랜드 이름 | FABIA |
| 인증 | ISO9001,BV,CCS,DNV |
| 모델 번호 | 2인치 ～ 87인치 |
| 문서 | 제품 설명서 PDF |
| 최소 주문 수량 | 1 세트 |
| 가격 | 협상 가능 |
| 포장 세부 사항 | 판지/나무 케이스 |
| 배달 시간 | 15-30 작업 일수 |
| 지불 조건 | L/C (신용장), 인수 인도, D/P (지급도 조건), 전신환, 머니그램, 웨스턴 유니온 |
| 공급 능력 | 주당 100-1000세트 |
제품 상세 정보
| 제품 이름 | 트리플 엑센트릭 마린 버터플라이 | 밸브 응용 | 환기 |
|---|---|---|---|
| 밸브 재료 | 스테인리스 스틸 | 밸브 연결 | 플랜지됩니다 |
| 밸브 작동 | 영적인 | 밸브 인증 | BV,DNV,CCS |
| 밸브압 | ≤0.25MPa | 밸브 씰 | 스테인리스 스틸 |
| 밸브 크기 | 2-87인치 | 밸브 온도 | 500C |
| 밸브형 | 나비 | ||
| 강조하다 | 세 개의 특이한 해상 나비 밸브,높은 성능의 해상 나비 밸브,해상 나비 밸브 고성능 |
||
제품 설명
Triple eccentric marine butterfly valve High Performance For Diesel Engine Exhaust Gas Treatment System
1. Description:
In the Marine field, FB-D-73 series butterfly valves are mainly used to deal with diesel engine exhaust gas treatment system, through the supporting actuator to adjust or cut off the exhaust gas in the system aisle, so as to achieve Marine nitrogen
oxide emissions to meet the requirements of relevant standards. At present, the main application of waste gas treatment systems are SCR system, ICER system, etc.
In addition, FB-D-73 series butterfly valves have also been widely used in the road industry, such as steam desorption ads- orption pipes in VOCs and some other gas pipelines that require strict leakage rates.
2. Specification:
| FABIA Valve Parameter List | ||
| Valve type: | Flange type heavy-duty ventilation butterfly valve | |
| Size: | 2inch ～ 87 inch | |
| Material: |
316/316L/304/304L/ Corten |
|
| Connection type: | Flange Connection | |
| Driving model: | Manual/Worm gear drive/Pneumatic/Electric | |
| Pressure rating: | ≤0.25Mpa | |
| Temperature: | -≤500℃ | |
| Model: | FB-D-73.......... | |
3. Features:
- three eccentric structure,wideoblique valveseat design
- Suitable for low pressure air or other gas flow, pressure control and high temperature gas
- Zero air leakage
- CCS&DNV Type approval certificate, BV French Classification Society Factory approval certificate and product type approval certificate.
- Strong Corrosion Resistance: Manufactured with high-quality corrosion-resistant materials, suitable for harsh operating environments.
- Precise Control: High-precision control system ensures accurate adjustment of gas flow.
- Excellent Sealing: Well-designed sealing structure reduces leakage rate.
- Fast Response: Quick opening and closing enhance system response speed.
- Simple Structure: Easy maintenance minimizes downtime.
- High Temperature Resistance: Able to withstand high-temperature conditions reliably.
